81117
RATCHET AIR WRENCH
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Toolholder size
1/2" (12.7 mm)
Toolholder type
Driver
Max. working pressure
0.63 MPa
Rotations
0-150 min⁻¹
Max. torque
61 Nm
Required air flow
141 l/min
Air connection diameter (PT)
standard
Air supply hose inside diameter
3/8" (9.5 mm)
Length
254 mm
Acoustic pressure
92.1 dB(A)
Acoustic power
103.1 dB(A)
Vibrations
0.8 m/s²
Weight
1.2 kg
Set includes
pneumatic ratchet, hose connector
Symbol
81117
VOREL air ratchet, angle 1/2''
- Length [mm] 254 .
- Weight [kg] 1.2
- Air connection (PT) diameter [‘’] / [mm] 1/4 / 6.3
- Diameter of air supply hose (internal) [‘’] / [mm] 3/8 / 10
- Rotational speed [min-1] 150
- Maximum torque [Nm] 61 Drive size [‘’] / [mm] 5 1/2 / 12.5
- Maximum operating pressure [MPa] 0.63
- Required air flow (at 6.2 bar) [l/min] 141
- .Sound pressure (EN ISO 15744) [dB(A)] 91.0 ± 3.0
- Sound power (EN ISO 15744) [dB(A)] 102.0 ± 3.0
- Vibration (ISO 28927-2) [m/s2] 3.27 ± 1.5
