YT-3703
TILE CUTTING MACHINE
- Profesjonalny przyrząd do cięcia glazury o max długości cięcia 630 mm.
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Functions
straight cut, cutting at an angle
Max. tile thickness
14 mm
Cutting length
630 mm
Horizontal cutting angle
0-45 ˚
Base dimensions
760x175 mm
Cutting wheel dimensions
12.6x3x3 mm
Material
steel, PVC
Blade material
YG6X
Blade finish
titanium nitride coated
Weight
10.5 kg
Set includes
tile cutting device, angle
Application
glaze
Symbol
YT-3703
![](https://pim.toya.pl/piktogramy/mm/image-thumb__80318__Sklep_pikto/630_mm.png")
![](https://pim.toya.pl/piktogramy/ANGLE_DEGREE_st/image-thumb__50719__Sklep_pikto/0-45_DEGREE.png")
![](https://pim.toya.pl/piktogramy/CUTTING/image-thumb__70094__Sklep_pikto/max_THICKNESS_14_mm.png")
![](https://pim.toya.pl/piktogramy/BRAKE_WHEEL/image-thumb__70102__Sklep_pikto/WHEEL_12%2C6x3x3_mm.png")
![](https://pim.toya.pl/piktogramy/MATERIALS/image-thumb__60939__Sklep_pikto/YG6X.png")
![](https://pim.toya.pl/piktogramy/MATERIALS/image-thumb__60936__Sklep_pikto/TiN.png")
Precise Cutting of Tiles
Discover professionalism with YT-3703 - a tool designed for perfect cutting and breaking of tiles. Precision and durability in one device.
Mastery in Every Cut: Professionalism and Precision
- Professional tool for cutting tiles with a maximum length of 630 mm
- Base with two tiltable, metal trays facilitates breaking hard tiles
- Single steel guide ensures stable and precise knife guidance
- Precise scale allows for cutting tiles of a specific width
- YG6X sintered carbide blade ensures long life and efficiency
- Ability to cut tiles up to 14 mm thick
- Allows for straight and angled cuts from 0-45 degrees
Precise Cutting
Precise Breaking
Angle Cutting
Sturdy Construction
Durable Blade
Technical Specifications
- Max. cutting length: 630 mm
- Max. tile thickness: 14 mm
- Blade material: YG6X sintered carbide, titanium nitride coated
- Cutting wheel dimensions: 12.6x3x3 mm
- Cutting angle in the horizontal plane: 0-45°
- Material: steel, PVC
- Weight: 10.5 kg
- Base dimensions: 760x175 mm
- Set includes: tile cutting tool, square
Usage warnings:
Use of hand tools may be dangerous! Always use personal protection equipment at work. Use only proper undamaged tools. Select the type and size of tool according to intended application. Do not overload tools. Keep tools away from children. Use tools with proper care.Ask a question
