71804
CONNECTION HOSE F/F 1/2" 1/2" 800MM
- Elastyczny wąż przyłączeniowy w oplocie ze stali nierdzewnej. Długość 800mm. Gwint przyłączeniowy: żeński 1/2" x żeński 1/2".
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Length
800 mm
Material
stainless steel, EPDM rubber
Internal diameter
8 mm
External diameter
12 mm
Connector thread size
G1/2(F) x G1/2(F)
Water flow
32 l/min
Max. pressure
1 MPa
Max. temperature
70 ˚C
Application
connecting toilet flushers, connecting valves
Symbol
71804
Flexible stainless steel braided connection hose. It is designed for hot and cold water. It is approved by PZH for contact with drinking water. Rubber hose made of EPDM rubber, brass connections nickel-plated, EPDM rubber gasket.
Purpose/Application
It is designed from connecting toilet cisterns or valves.
Parameters
- Material: rubber
- Length [mm]: 800
- Max. pressure [MPa]: 1
- Average flow [l/min]: 32
- Inner diameter [mm]: 8
- Outside diameter [mm]: 12
- Connection threads: female 1/2" x female 1/2"
