YT-85401
GASOLINE WATER PUMP 2" 4 KW 30M3/H
- Spalinowa pompa wodna.
Brand
Symbol
YT-85401
Producer code
5906083854019
Series
Engine power
4 kW
Turnout of the engine
3600 min⁻¹
Engine capacity
208 cm³
Max. capacity
30 m³/h
Max. pumping height
25 m
Suction maximum
8 m
Water connection diameter
2 (50 mm)"
Max. Diameter of mechanical pollutants
50 mm
Water temperature
45 ˚C
Fuel Type
Unleaded petrol
Fuel tank capacity
3.6 l
Max. fuel consumption
1950 g/h
Oil type
SAE 15W-40
Oil tank capacity
0.6 l
Carrying handle
No
Colic
No
Dimensions
485x415x415 mm
Cooling
air
Type of engine
CP170F
Spark plug type
F7RTC
The number of cylinders in the engine
1
The number of bars in the engine
4
Acoustic pressure
82.1 ± 3.0 dB(A)
Acoustic power
95.4 ± 3.0 dB(A)
Weight
25 kg
The pump is designed for pumping large amounts of water.
For rescue work after accidents and natural disasters.
The pump and the internal combustion engine are built into a steel frame to protect against damage and facilitate transportation.
Parameters:
- maximum Lifting height [m]: 25
- engine capacity [cm3]: 196
- fuel tank capacity [l]: 3.6
- oil tank capacity [l]: 0.6
- net weight [kg]: 25
- maximum capacity [dm3/ h]: 30000
- connection diameter: 2”
- maximum dirt diameter [mm]: 50
