YT-17262
FARM JACK 3T 60"
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Load capacity
3 t
Lifting range
125-1320 mm
Lifting capacity
3 (125 mm ≤H <305 mm), 2.25 (305 mm ≤H <610 mm), 1.5 (610 mm ≤H <915 mm), 0.75 (915 mm ≤H <1220 mm), 0.375 (H≥1220 mm) t
Size
60" (1530 mm)
Dimensions
1515x245x140 mm
Min. load capacity
75 kg
Weight
14 kg
Application
for lifting vehicles with a high chassis, including off-road vehicles, as well as agricultural machines and equipment, as a puller or spreader
Symbol
YT-17262
Description:
Ideal for lifting vehiclesós with high-suspended chassis, including off-road cars, as well as agricultural machinery and equipment. Can be used as a puller or spreader.
- lifting capacity of up to 3 tons
- foot allows the jack to be used on any surface
- very easy to change the direction of góra–dół
- enable to pull out „buried” car in several minutes
Technical data:
- Lift dimensions: 1515x245x140mm
- Weight: 14kg
Usage warnings:
Before using the lift, read the instructions carefully.Do not exceed the lifting capacity.
The lift must be placed on a strong, even and stable surface.
Do not perform any work under a raised and unsecured vehicle.
