YT-17261
FARM JACK 3T 48"
Brand
Symbol
YT-17261
Producer code
5906083041945
Series
Load capacity
3 t
Lifting range
125-1060 mm
Lifting
3 (125 mm ≤ H < 305 mm), 2.25 (305 mm ≤ H < 610 mm), 1.5 (610 mm ≤ H < 915 mm), 0.75 (H ≥ 915 mm) t
Size
48 (1230 mm)"
Dimensions
1235x245x140 mm
Min. load
75 kg
Weight
13 kg
Application
For lifting vehicles with a high -suspended chassis, including off -road cars, as well as agricultural machines and devices, as a welt or a spreader
Description:
Ideal for lifting vehiclesós with high-suspended chassis, including off-road cars, as well as agricultural machinery and equipment. Can be used as a puller or spreader.
- lifting capacity of up to 3 tons
- foot allows the jack to be used on any surface
- very easy to change the direction of góra–dół
- enable to pull out „buried” car in several minutes
Technical data:
- Lift dimensions: 1235x245x140mm
- Weight: 13kg
