YT-84893
GASOLINE CHAINSAW 1,1HP 30CM
Brand
Symbol
YT-84893
Producer code
5906083090684
Series
Power
0.75 kW
1 KM
Engine capacity
25.4 cm³
Turnout of the engine
8500 min⁻¹
Turnout of the engine idle gear
3000 min⁻¹
Guide length
12 (300 mm)"
Length of cut
300 mm
Chain type
HY-JL9D-0.050x45
Chain scale
3/8" (9.525 mm)
Max. chain travel speed
12.95 m/s
The number of links
45
Number of teeth of the chain drive wheel and scale
6 teeth x 9,525 mm
Chain guide type
ZLA12-15-509P
Attachment type
IN
Fuel Type
Unleaded petrol
Fuel tank capacity
280 cm³
Fuel and oil proportion
40:1
Max. fuel consumption
0.36 kg/h
Oil tank capacity
200 cm³
Automatic chain lubrication
Yes
Cooling
air
Spark plug type
L8RTF
The number of cylinders in the engine
1
The number of bars in the engine
2
Acoustic pressure
95.4 ± 3.0 dB(A)
Acoustic power
108.4 ± 3.0 dB(A)
Vibrations
7.199 ± 1.5 / 7.492 ± 1.5 m/s²
Weight
3.94 kg
Contents of the set
chainsaw, chain guide, cutting chain, guide cover
For chains
YT-849495
To the guides
YT-849381
Lightweight and easy to maneuver petrol chainsaw. Thanks to its very high power it cuts both branches and boughs as well as trunks well.
- engine: 2-stroke, single cylinder
- chain pitch: 3/8 inch
- bar size: 12 inches (AP12-45-509P)
- capacity: 25.4 cm3
- nominal power output: 0.75 kW
- fuel tank capacity: 280 ml
- oil tank capacity: 200 ml
- engine idle speed: 3000 rpm
- maximum engine speed: 8500 rpm
