YT-55841
VERTICAL SANDBLASTER CABINET 220L
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Power
12 W
Operating pressure
0.27-0.82 MPa
Max. pressure
0.82 MPa
Voltage
230 V a.c.
Frequency
50 Hz
Required air flow
424-707 l/min
Air connection diameter (PT)
standard
Max. abrasive volume
17 l
Capacity
220 l
External dimensions
1380x940x580 mm
Working part dimensions
370-540x840x560 mm
Air supply hose inside diameter
3/8" (9.5 mm)
Material
steel sheet
Surface finish
sandblasted
Output voltage
12 V d.c.
Output current
1 A
Acoustic pressure
63.5 ± 3.0 dB(A)
Acoustic power
65.0 ± 3.0 dB(A)
Vibrations
<2.5 m/s²
Weight
43 kg
Set includes
sandblaster, sandblasting gun, a hose sucking abrasive, air connection hose with spigot, nozzle x4 (Ø4, Ø5, Ø6, Ø7 mm), lamp power supply, window protection foil x4, gloves,
Set includes cont’d
PTFE tape
Symbol
YT-55841
- material: sheet steel
- surface finish: sandblasted
- capacity: 220 l
- weight: 43 kg
- power: 12 W
- required air flow: 424-707 l/min
- air connection diameter: standard
- Outer dimensions: 1380x940x580 mm
- inner diameter of the air supply hose: 3/8" (10.0 mm)
- dimensions of working part: 370-540x840x560 mm
- maximum abrasive volume: 17 l
- scope of delivery: sandblaster, sandblasting gun, abrasive suction hose, air connection hose with connection nozzle, nozzle x4 (Ø4, Ø5, Ø6, Ø7 mm), power supply for lamp, window protection foil x4, gloves, Teflon tape
Usage warnings:
Warning! Secure the door before starting work. An unsecured door can cause serious injury. Warning! Disconnect the machine from the air and electric power supply before maintenance. 1 Clean the filter and dust collector frequently. 2. check the wear of parts, such as nozzles, orifices and gloves. 3. check the abrasive. Abrasive wears out and should be replaced periodically. 4. Periodically clean the interior of the sandblaster cabin. 5. Avoid moisture in air lines and abrasive. 6. Check the tightness of the door once a week. 7. Do not exceed the maximum air pressure.To download
