Novelty
YT-85394
PRESSURE SWITCH PC-59
Brand
Entity responsible for this product in the EU
TOYA S.A.More
Address:
Sołtysowicka 13-15Postal code: 51-168City: WrocławCountry: PolskaE-mail: info@yato.pl
Series
Type of
PC-59
Water outlet diameter
1" (25.0 mm)
Max. power
1100 W
Ciśnienie początkowe
0-6 bar
Ciśnienie zatrzymania
2-10 bar
Voltage
220-240 V a.c.
Frequency
50/60 Hz
Max. current
10 A
Material
PP
Auto power on / off
yes
Manualna regulacja ciśnienia
yes
Zabezpieczenie przed suchoobiegiem
yes
Cable length
1 (wejście), 0.5 (wyjście) m
Max. water temperature
60 ˚C
Ambient temperature
5~40 ˚C
Protection grade
IP65
Weight
0.4 kg
Application
do automatycznego sterowania pracą pomp wodnych
Symbol
YT-85394
The pressure switch provides constant water pressure for garden irrigation or domestic water supply.
The line pressure in the connected system is monitored by a pressure switch. The water pump is automatically started and stopped according to the opening and closing of the valve.
Product benefits:
- monitors water pressure
- ensures constant water pressure
- protects against dry running
Technical specifications:
- type: PC-59
- initial pressure: 0–6 bar
- max. pressure 10 bar
- voltage: 220-240 V
- rated current: 10A
- max. power 1.1 kW
- max. liquid temperature 60°C
- max. ambient temperature 40°C
- protection rating: IP65
- housing material: polypropylene
- input: 1 m cable
- output: 0.5 m cable
