A digital paint and coating thickness gauge used for magnetic and non-magnetic materials. Performs precise measurements on various surfaces, automatically detected, allowing for the evaluation of coating quality. Used in the automotive, metal, and chemical industries.

The measurement range of the paint coating thickness is from 0 to 1.3 mm, and consideration of the radius of curvature guarantees reliable readings of the tester even on curved or angled surfaces.

• for iron and non-iron coatings - steel, copper, aluminum
• automatic detection of the tested material substrate
• measurement range: 0-1.3 mm (0-1300 μm)
• measurement accuracy: +/-3% + 2 μm
• result resolution: 0.1 µm
• min. convex radius: 1.5 mm
• min. concave radius: 25 mm
• min. diameter of the measurement area: 6 mm
• min. tested thickness: iron 0.5 mm, others 0.3 mm
• memory of the last 20 results
• high-resolution screen
• self-test function
• operating temperature: 0-40℃
• operating humidity: 20-90%, relative humidity: <80%
• power supply: 2 AAA batteries, 1.5 V
• dimensions: 105 x 52 x 25 mm
• weight: 100 g
